技术参数： Technical Specifications
Name 3 in 1 Magneto IPL and Laser Machine
Voltage 110V/220V 50/60HZ
Screen 8 inches LCD digital touch screen
Machine Size 53*50*118cm
N.W 42KG
MAGNETO OPTIC IPL
Energy Density 1-50J/cm2
Frequency 1-6Hz
Discharge Interval 1s, 2s, 3s, 4s (variable)
Shots 200000 shots each handle
Mode HR: Hair removal
SR: Skin rejuvenation
Filters No need to change filters
RF
Energy Density RF:1-20J/cm2
Handle Size Diameter 43mm/30mm/15mm
Frequency 3p/s
Delay 50-2500ms
Probe TEMP -2°C~0°C
Q-Switch Nd Yag Laser
Frequency 1-10p/s
Energy 1-2000mj
Wavelength 1064nm/532nm/1320nm (BDLS)
Water Alarm YES
Tempreture Alarm YES
工作原理： Working Principle
360 magneto-optical hair removal system principles is divided into two parts, one is the principle of photo pyrolysis of the IPL pulse and the other is the strong magnetic energy. Magnetic light is an intelligent and non-stripping skin reconstruction system with the technology of epidermal cooling technology, magnetic energy and multi-band IPL. Magnetic light combines the above technologies to provide targeted treatment for different skin types and different skin problems. Under the premise of the full protection of the epidermis (epidermis cooling technology), the use of magneto-optical technology can be a unique decomposition of the epidermis and dermis pigments (such as: zygomatic brown glider, etc.), it couldmaximum focus to the dermal collagen tissue and hair follicles of the hairy nipples.
优势： Advantages
1.Magneto-optic Handle:No need to replace filter, the machine automatically select the wavelength required and permanent hair removal.
2. 360 magneto OPT was originally designed for fast hair removal working mode.Its optimal energy and cooling system support machine working at long time continuously;
3.It has a absolute energy advantage against other similar OPT systems in market which releases less and less energy for each shot in process of continuous flashing
4. The energy of 360 magneto OPT is 3~5 times more than general device. Improper handle would lead to a very high temperature on crystal heating the skin.
5. While 360 magneto OPT is equipped with a special water cooling system and installed with a complete sapphire as light guide.That is of vital importance to ensure stableness of system and comfort of treatment.
特征： Features
360 Mageto Optic SHR
1. Permanent hair removal.
2. Pigmentations treatment (Spots removal,smallpox removal,freckle removal).
3. Skin rejuvenation (Tighten skin,fine wrinkles removal,whiten skin).
4. Acne Treatment.
5. Vascular Therapy.
Cool RF
1. Wrinkles removal.
2. Tighten skin.
3. Lift skin.
4. Rebuild face outlines and body contours.
5. Contract large pores.
Nd YAG Laser
1. All colors of tattoo removal.
2. Spots removal(freckle,coffee spots,age spots,nevus of Ota).
3. Embroidery lipline.
4. Eyeline,eyebrow pigments removal
